Name: Control Cage, Impeller case
Materials: High chromium alloy cast iron, high manganese alloy steel
Applicable machine: Shot blasting machine
Applicable media: Steel grit or shot
Customizable or not: Yes
Part model: Based on customers needs
Order quantity: Based on customers needs
In the blast wheel assembly, the control cage is mounted around the impeller. Shots are discharged from the opening of the impeller case and threw on to the high speed rotating blades. The shot blast replacement parts exert an important role in metal surface treatment applications.
Blast Wheel Structural Diagram
Casting parts is proud to customize replacement control cages for SINTO, DISA, PANBORN, WHEELABRATOR and OMSG shot blasting machines
1. Samples for Russian customer
2. Samples for Malaysian customer
High chromium alloy cast iron | High manganese alloy steel | |||||||
Chemical compositions % | C | 2.7-3.1 | Mechanical properties | Tensile strength kg/mm2 | ≤ 40 | Chemical compositions % | C | 0.9-1.3 |
Si | <1.0 | Si | ≤0.8 | |||||
Mn | 0.8-1.1 | Hardness HS | > 70 | Mn | 11-14 | |||
P | <0.06 | P | <0.07 | |||||
Cr | 25-30 | Impact resistance kgm/cm 2 | > 0.3 | S | <0.05 | |||
S | <0.05 | 0 | 0 |
